When you are dealing with any system, especially one publicly
accessible service or one with multiple users, you need to make sure it
has not been tampered with. Implementing an intrusion detection system
(IDS) is a good way to do a routine sanity check on the system.
There a few products like Tripwire and AIDS offering intrusion detection packages, but you may want a simpler solution. Perhaps you do not have a need for all the bells and whistles of the larger packages like pretty graphics and pie graphs for the manager types. You want it simple and you need something that just works. You may want to look at making your own IDS using mtree.
By making your own system, not only can you audit the files on the disk but also audit the IDS itself. You would have control of how the IDS ran, how and where it looks at files and what it does when or if a problem is found. Take a look at the binary "mtree" which is installed by default on most open source systems.
To get started, make a directory owned by root with (chmod 700) which in our example will be called /ids_dir . This directory will contain the single IDS shell script and the hash check files generated by mtree. Lets look at the simple shell script making up our custom IDS solution. We are going to name the script "ids.sh", but can can name it anything you like.
First, you need to have the binary called mtree (OpenBSD or FreeBSD) or freebsd-mtree (Ubuntu linux). Mtree is installed on OpenBSD and FreeBSD by default. If you are running Ubuntu Linux just install the package, "sudo apt-get install freebsd-buildutils". Once you have the binary set the script variable MTREE to the binary name. NOTE: the shell script is running in bash so make sure the shebang, "#!/usr/local/bin/bash" actuall points to bash. This means #!/usr/local/bin/bash on OpenBSD and #!/bin/bash on Ubuntu for example.
The script has two variables you need to set before executing it. The first is the $KEY variable. This sets a seed value necessary to generate the hash on the files. It is a randomly generated 23 digit number you can make up for this purpose. The same $KEY value is also needed to verify the hash values against. If an unauthorized person had the has files, but not the $KEY value, then they would not be able to check or spoof the validity of your files. The second variable id $DIR. This is the directory that the script and hash checked files generated by mtree will reside.
#!/usr/local/bin/bash
#
## Calomel.org ids.sh
#
if [ $# -eq 0 ]
then
echo ""
echo " Calomel.org ./ids.sh \$arg"
echo "--------------------------------------"
echo "generate = generate IDS signatures"
echo "verify = verify files against known signatures"
echo ""
exit
fi
## mtree binary (OpenBSD: mtree and Linux: freebsd-mtree)
MTREE=mtree
## IDS seed signature key
KEY=12345946598234534539234
## IDS signature directory
DIR=/ids_dir
if [ $1 = "generate" ]
then
rm -rf $DIR/mtree_*
cd $DIR
$MTREE -c -K cksum -s $KEY -p /bin > mtree_bin
$MTREE -c -K cksum -s $KEY -p /sbin > mtree_sbin
$MTREE -c -K cksum -s $KEY -p /usr > mtree_usr
logger IDS generate IDS signatures
chmod 600 $DIR/mtree_*
exit
fi
if [ $1 = "verify" ]
then
cd $DIR
$MTREE -s $KEY -p /bin < mtree_bin >> temp 2>1
$MTREE -s $KEY -p /sbin < mtree_sbin >> temp 2>1
$MTREE -s $KEY -p /usr < mtree_usr >> temp 2>1
cat temp | mail -s "`hostname` file integrity check" root
rm temp
logger IDS verify files against known signatures
exit
fi
The script is split into two parts, generate and verify. To start a hash check of all the directories listed and files in those directories you execute the script "ids.sh" with the argument "generate". To verify the hash values against the files currently on the system execute the script "ids.sh" with the argument "verify". During the verify process an email with the results are sent to the root user.
Now that you have made the /ids_dir, copied the script "ids.sh" into /ids_dir and made up a new 23 digit value for KEY we are ready to run ids.sh for the first time. Execute the command "./ids.sh generate". Once ids.sh finishes you will see three files in the /ids_dir directory containing the hash values for all of the directories and files mtree checked under /bin, /sbin and /usr. You are welcome to open up the mtree_* files and take a look at the hashes and file info.
-rwx------ 1 root 321 Jan 10 10:20 ids.sh -rw------- 1 root 234567 Jan 10 10:20 mtree_bin -rw------- 1 root 34567 Jan 10 10:20 mtree_sbin -rw------- 1 root 1234567 Jan 10 10:20 mtree_usr
These mtree_* files are the files we will make all subsequent IDS checks against. Be sure only authorized admins can access these files and make an off system copy to be safe. A copy on CD in a safe is preferable, but a personal encrypted usb key will work too. Also make sure to backup the 23 digit $KEY variable as an authorized admin can _not_ do a hash check without it.
Now it is time to run "./ids.sh verify" which we will verify the files on the system are the same files we hash checked. After you run the check script an email similar to the one below will be sent to root. If all the files are the same then the mail will look like this one.
From: root@your_machine.org (Root User) To: root@your_machine.org Date: Fri, 13 Jun 2910 10:20:30 -1000 (FDT) Subject: machine.domain.lan file integrity check mtree: /bin checksum: 893663885 mtree: /sbin checksum: 1746129196 mtree: /usr checksum: 1666010597
If mtree finds a file that has been modified, deleted or added since the last run of "./ids.sh generate" the file(s) will be listed in the email. You should track down why the change was made and if it is legitimate. Then, if the change was legitimate, you should re-run the command "./ids.sh generate" to update the hash files.
From: root@your_machine.org (Root User)
To: root@your_machine.org
Date: Fri, 13 Jun 2910 20:20:30 -1000 (FDT)
Subject: machine.domain.lan file integrity check
mtree: /bin checksum: 893663885
mtree: /sbin checksum: 3292978967
local/sbin:
modification time (Fri Jun 13 10:20:30 2910, Fri Jun 13 20:20:30 2910)
local/sbin/route:
size (5099786, 5105218)
modification time (Fri Jun 13 10:20:30 2910, Fri Jun 13 20:20:30 2910)
cksum (1813282464, 116976809)
local/sbin/reboot:
size (5041903, 5099786)
modification time (Fri Jun 13 10:20:30 2910, Fri Jun 13 20:20:30 2910)
cksum (2712827374, 1813282464)
mtree: /usr checksum: 1666010597
Finally, setup a cron job to run the "ids.sh verify" commanded script and review the emails when they arrive. This cron job will run the script every 6 hours for example.
#minute (0-59) #| hour (0-23) #| | day of the month (1-31) #| | | month of the year (1-12 or Jan-Dec) #| | | | day of the week (0-6 with 0=Sun or Sun-Sat) #| | | | | commands #| | | | | | #### file integrity check 00 */6 * * * /ids_dir/ids.sh verify
